Products Category
50kw electric generator
Post Time : 2013-03-11
- KAKA-W50
- NINGBO,CHINA
- YELLOW AND WHITE
- KAKA
Product Details
| Model | HMD50W | |
| Genset Output Power | 50KW | |
| Rated Voltage | 380V/220V | |
| Genset | Frequency | 50HZ |
| Power Factor (COS) | 0.8 | |
| Dimension | 2200 x 740 x 1500 | |
| Net Weight | 1380KG | |
| Engine Model | TD226B-4D | |
| Engine Structure | In-line,four-cylinder,4-stroke | |
| Rotating Speed | 1500RPM | |
| Engine Cooling Method | Radiator for ambient temp 40 degrees, belt driven cooling fan with cover | |
| Engine Filter System | Dry type air filter, fuel filter, oil filter | |
| Engine | Governor System | Mechanical governor system |
| Aspiration Mode | Turbo | |
| Starting Method | 24V DC electric starting | |
| Displacement | 4.16L | |
| Bore x Stroke | 105 x 120mm | |
| Full Load Consumption | 13.6L | |
| Model | TWG2E | |
| Excite Type | Brushless, self-exciting, AVR automatic voltage regulation | |
| Connecting Type | 3-phase/ 4 wires | |
| Alternator | Steady Frequency Change | 0.50% |
| No-loaden Voltage | >=95% | |
| Steady Voltage | <=±1% | |
| Insulation Degree | H | |
| Enclosure Degree | IP21 |
